₨253.00 3S 20A Lithium Battery 18650 Charger BMS Protection Board 12.6V 18650 Li-ion Cell Charging Module 11.1V 12V 12.6V
SKU: N/A- تفصیلات:1. 3 سیریز 12.6V 20A لتیم بیٹری پروٹیکشن بورڈ (ریکوری فنکشن کے ساتھ -آٹو ریکوری)درخواست: 3.6V، 3.7V کے برائے نام وولٹیج والی لتیم بیٹریاں (بشمول 18650، 26650، پولیمر لتیم بیٹریاں)2. پروڈکٹ کا سائز: 59 * 20 * 3.4 ملی میٹر3. چارجنگ وولٹیج: 12.6V-13.0V4. مسلسل ڈسچارج کرنٹ (بالائی حد): 20A (اگر گرمی کی کھپت کا ماحول اچھا نہیں ہے، تو براہ کرم لوڈ کرنٹ کو کم کریں)5. مسلسل چارج کرنٹ (بالائی حد): 10Aپیکیج شامل:
- 1PCS * 3S 20A لتیم بیٹری 18650 چارجر PCB BMS پروٹیکشن بورڈ
₨498.00 3S 60A BMS Li-ion Lithium Battery Charger Protection Board 18650 BMS 11.1V 12V
SKU: N/A- 3S 12.6V 60A lithium battery protection board
- Scope: Suitable for lithium battery with 3.7V nominal voltage and 4.2V limited charge voltage. (includes 18650,26650, polymer lithium battery)
- Size:41*55*3.4mm(Enhanced version),41*62*3.4(Balanced version).
- Weight:8.8g(Enhanced version),9.8g(Balanced version).
- Charging voltage: 12.6V – 13.6V
- Continuous discharge current (upper limit): 60A (if the cooling environment is not good, please reduce the load current)
- Continuous charge current (upper limit): 15A
- Enhanced version: suitable for electric drill with starting current below 120A and power below 260W .(without balanced charging function)
- Balanced version: suitable for electric drill with starting current below 120A and power below 260W .(with balanced charging function)
₨340.00
HC-SR501 HC SR501 PIR Human Motion Infrared Detector Sensor Module
SKU: N/A- PIR Sensor – Proximity IR Sensor
- Input Voltage: DC 4.5-20V
- Static current: 50uA
- Output signal: 0,3V or 5V (Output high when motion detected)
- Sentry Angle: 110 degree
- Sentry Distance: max 7 m
- Shunt for setting override trigger: H – Yes, L – No
- The Sensitivity and Holding Time Can be Adjusted
- Blockade time: 2.5s (Default)
- Sensitive Setting: Turn to the Right, Distance Increases (About 7M); Turn to the Left, Distance Decreases (About 3M)
- Time Setting: Turn to Right, Time Increases (About 200S); Turn to Left, Time Reduce (About 5S)
₨98.00 Power Bank Module Mini 5V 1A Single Port Circuit
SKU: N/A- Built-in charging and discharging power MOS
- Input voltage: 3.7V~5.5V
- Charging current: up to 1A
- Output current: up to 1A
- Output voltage: 5V
- BAT discharge termination voltage: 2.9V
- Preset 4.2V charging voltage with an accuracy of ±1%
- Discharge efficiency: 85% (input 3.7V, output 5V/1A)
- Maximum 8uA standby current
- Integrated charge management and discharge management
- Intelligent temperature control and over temperature protection
- Integrated output overvoltage protection, short circuit protection, heavy duty protection
- Integrated overcharge and overdischarge protection
- Supports turbulence mode and zero voltage charging
